Nor-Lake 8X36X7-7 COMBO1

Thermometer, lights, trim & locks

14" x 24" 3-pane heated viewport with heated glass and frame heater, for freezer use only +$880.70 14" x 24" 3-pane unheated viewport with frame heater +$798.10 24" LED Light Fixture (Shipped Loose) +$282.79 48" LED Light Fixture (Shipped Loose) +$282.79 9" LED Light Fixture - 120 volt only (shipped loose) +$218.15 Trim Strip, 3" x 3" x 8'-7" angle, galvanized, for walk-in +$23.34 Trim Strip, 6" x 8'-7" flat, galvanized, for walk-in +$23.34

Compartment configuration

Cooler compartment without floor on left, compartment with floor on right (LF/WF) Cooler compartment without floor on right, compartment with floor on left (WF/LF)

Second compartment door size

Door size 26" x 78" Door size 30" x 78" Door size 36" x 78"

First compartment door size

Door size 26" x 78" Door size 30" x 78" Door size 36" x 78"

Floor options

Exterior Ramp, for walk-ins with floors +$488.83 Interior Ramp, 30" (allow 10 days for interior ramps) +$510.82 Interior Ramp, 36"(allow 10 days for interior ramps) +$510.82 Non-Skid Floor Strips, (Shipped loose) price per strip +$4.94

First compartment door hinging

First Compartment Door hinged on left, specify door location with sketch First Compartment Door hinged on right, specify door location with sketch

Second compartment door hinging

Second Compartment Door hinged on left, specify door location with sketch Second Compartment Door hinged on right, specify door location with sketch

Cooler Compartment, +35F Indoor/Outdoor Normal load compressor

Medium Temp Condensing Unit, pre-assembled high ambient, hermetic remote refrigeration, 8658 BTU @ +25°F suction +35°F cabinet @ 100°F ambient, R-448A/R-449A, pre-wired/mounted accessories, 208-230v/60/1-ph, 15 amps, 1 HP, Made in USA +$2,708.96 Medium Temp Condensing Unit, pre-assembled high ambient, hermetic remote refrigeration, 8975 BTU @ +25°F suction +35°F cabinet @ 100°F ambient, R-448A/R-449A, pre-wired/mounted accessories, 208-230v/60/3-ph, 15 amps, 1 HP, Made in USA +$2,926.66

Cooler Compartment, +35F Indoor/Outdoor Heavy load compressor

Medium Temp Condensing Unit, pre-assembled high ambient, Scroll remote refrigeration, 11,028 BTU @ +25°F suction +35°F cabinet @ 100°F ambient, R-448A/R449A, pre-wired/mounted accessories, 208-230v/60/1-ph, 20 amps, 1-1/4 HP, Made in USA +$3,426.27 Medium Temp Condensing Unit, pre-assembled high ambient, Scroll remote refrigeration, 12,768 BTU @ +20°F suction +35°F cabinet @ 100°F ambient, R-448A/R449A, pre-wired/mounted accessories, 208-230v/60/3-ph, 20 amps, 1-1/4 HP, Made in USA +$3,591.45

Freezer Compartment, -10F Indoor/Outdoor Normal load compressor

Low Temp Condensing Unit, pre-assembled high ambient, Scroll remote refrigeration, 8699 BTU @ -20°F suction -10°F cabinet @ 100°F ambient, R-448A/R-449A, pre-wired/mounted accessories, 2-1/2 hp, 208-230v/60/3-ph, Made in USA +$5,326.80 Low Temp Condensing Unit, pre-assembled high ambient, Scroll remote refrigeration, 8946 BTU @ -20°F suction -10°F cabinet @ 100°F ambient, R-448A/R-449A, pre-wired/mounted accessories, 2-1/2 hp, 208-230v/60/1-ph, Made in USA +$5,340.27
